The science of music reproduction and the art of Italy – Opera Loudspeakers
|
|
|
Cherry Veneer |
|
Mahogany Veneer |
|
|
|
|
|
|
Black Ash Veneer |
|
Walnut Veneer |
Specifications:
System: 2 way, front ported stand mount monitor
Drivers: 1 x 6.5” ScanSpeak aluminum cone
1 x 1” ScanSpeak ferro-fluid dome tweeter
Frequency Response: 40 Hz – 20k Hz
Crossover Frequency: 2000 Hz, low pass – 12 dB/ octave,
high pass – 12 dB/ octave
Power Handling: 10 – 70 watts RMS
Sensitivity: 91 dB/1watt/1 meter
Nominal Impedance: 4 ohm (Z min > 3.5 Ohms)
Dimension (HxDxW): 32 cm x 28 cm x 20 cm
Weight Each: 9.5 Kg
Retail Price – Cherry, Mahogany, or Black Ash Veneer: $2499.00 Per Pair
Specifications:
System: 2-1/2 way, rear twin-ported cabinet floor standing;
plugs for closing ports included
Drivers: 2 x 7” aluminum cone
1 x 1” ScanSpeak ferro-fluid silk dome tweeter
Frequency Response: 30 Hz – 30k Hz
Crossover Frequency: 2200 Hz, low pass – 12 dB/ octave,
high pass – 12 dB/ octave
Power Handling: 10 – 140 watts RMS
Sensitivity: 89 dB/1watt/1 meter
Nominal Impedance: 4 ohm (Z min > 3.2 Ohms)
Dimension (HxDxW) : 102 cm x 43 cm x 24.5 cm
Weight Each: 22.5 Kg
Retail Price – Cherry, Mahogany, or Black Ash Veneer: $4999.00 Per Pair
Specifications:
System: 3 way, rear twin-ported cabinet floor standing;
plugs for closing ports included
Drivers: 2 x 7” aluminum cone woofers
1 x 7” polypropylene with ABS phase plug cone midrange
1 x 1” ScanSpeak 9700 ferro-fluid silk dome tweeter
Frequency Response: 30 Hz – 30k Hz
Crossover Frequency: 300 Hz and 2000 Hz, low pass – 18 dB/ octave,
high pass – 18 dB/ octave
Power Handling: 10 – 140 watts RMS
Sensitivity: 91 dB/1watt/1 meter
Nominal Impedance: 4 ohm (Z min > 3.2 Ohms)
Dimension (HxDxW) : 110 cm x 43 cm x 24.5 cm
Weight Each: 25.5 Kg
Retail Price – Cherry, Mahogany, or Black Ash Veneer: $6999.00 Per Pair
Specifications:
System: 2 way, rear ported stand mount
Drivers: 1 x 7” polypropylene cone mid-woofer with re-cooked cone
and phase plug
1 x 1” Scanspeak 9700 ferro-fluid tweeter
Frequency Response: 40 Hz – 25k Hz
Crossover Frequency: 2000 Hz, mid-woofer – 12 dB/ octave, front
tweeters – 18 db/ octave
Power Handling: 10 – 100 watts RMS
Sensitivity: 89 dB/1watt/1 meter
Nominal Impedance: 4 ohm (Z min > 3 Ohms)
Dimension (HxDxW) : 42 cm x 42 cm x 24.5 cm
Weight Each: 15 Kg
Available in lacquered Walnut or lacquered Mahogany veneer.
Retail Price: $5999.00 Per Pair
Specifications:
System: 2.5 way, rear ported floor standing with rear-firing dipole
radiation system
Drivers: 1 x 8” magnesium long-throw cone woofers
1 x 7” polypropylene cone midrange with re-cooked cone
and phase plug
1 x 1” Scanspeak 9700 ferro-fluid tweeter (front firing)
2 x 1” Scanspeak 9700 ferro-fluid tweeter (rear firing)
Frequency Response: 30 Hz – 25k Hz
Crossover Frequency: 200 Hz and 2000 Hz, woofer – 12 dB/ octave,
midrange – 12 dB/ octave, front tweeter –
18 db/ octave, rear tweeters – 12 dB/ octave
Power Handling: 10 – 240 watts RMS
Sensitivity: 90 dB/1watt/1 meter
Nominal Impedance: 4 ohm (Z min > 3.2 Ohms)
Dimension (HxDxW) : 116 cm x 53.5 cm x 37 cm
Weight Each: 65 Kg
Available in lacquered Walnut or lacquered Mahogany veneer.
Retail Price: $11,999.00 Per Pair
Specifications:
System: 3 way, rear ported floor standing with rear-firing dipole
radiation system
Drivers: 2 x 8” magnesium long-throw cone woofers
1 x 7” polypropylene cone midrange with re-cooked cone
and phase plug
1 x 1” Scanspeak 9700 ferro-fluid tweeter (front firing)
2 x 1” Scanspeak 9700 ferro-fluid tweeter (rear firing)
Frequency Response: 32 Hz – 25k Hz
Crossover Frequency: 200 Hz and 2000 Hz, woofer – 12 dB/ octave,
midrange – 12 dB/ octave, front tweeters –
18 db/ octave, rear tweeters – 12 dB/ octave
Power Handling: 10 – 240 watts RMS
Sensitivity: 89 dB/1watt/1 meter
Nominal Impedance: 4 ohm (Z min > 3.2 Ohms)
Dimension (HxDxW) : 130 cm x 55 cm x 31 cm
Weight Each: 75 Kg
Available in lacquered Walnut or lacquered Mahogany veneer.
Retail Price: $14,999.00 Per Pair
|
